Amazing quality for a low price!
This demo model was used about 1 hour for photography.
You can buy KX5600V only from Keebomed. Portability, good image quality and affordability in one place!
- Light weight (10 Lbs) with battery and probe included (similar ultrasounds are about 20lbs)
- Two probe connectors like standard
- Sole veterinary ultrasound with DICOM as standard feature.
- Battery included like standards 4 hours
- LED monitor enables working outside in harsh sunlit conditions without sun shade.
- Large image-Images are displayed full screen, which is preferable even to other larger ultrasounds with 12" screen, since they do not have full screen images.
- Anti dust and anti splash keyboard convenient when working in dirty surroundings.
- Price--most affordable in its class--other similar model are above $4999.
- Rectal probe has 70mm lens and produces wide 70mm images which is important for determining large follicles.
- 10.4’ high resolution color LED backlight display with high contrast and wide viewing angle
- Adopt ARM7 embedded control system +FPGA signal processing system + well selected ultrasound hardware system, all make the unit more stable.
- Menu operation system with different languages (Spanish, English, French, Russian and Portuguese)
- Two probe sockets, auto-identify different optional probe
- Body marks：1.General 2.Bovine 3.Canine 4.Equine 5.Feline 6.Cardio 7.Swine, total 27 kinds body marks indicating probe position
- Display mode：B、2B、4B 、B/M、M
- Adjustable depth: 10 grades, max depth to 236mm
- Gray scale：256
- 8 steps intelligent TGC
- 8 kinds pseudo colors
- Image storage: 4G hard disk to permanently store about 5000 frames images；
- Cine loop：256 frames
- Puncture guide function with 2 correctable puncture guiding lines(adjustable angle & position)
- the gravel software package with real-time position line measurement
- Normal measurement: Distance, circumference, area (trochoid or ellipse), volume, etc.
- Cardio measurement：Depth, slope, heart rate, cycle
- OB measurement including: Cattle, dogs, horses, cats, goats, camels and sheep and pre-gestational age birth
- Other measurement: pig’s meat factor measurement
- OB report function
- One-key store: concise and practical
- One-key review：fast, practical image review function
- One-key Print
- One-key Transfer the current frozen image to net workstation to complete its image text report and print directly
- Concise and practical, easy operation. The system includes network workstation to complete data & report management (You don’t need to invest more to buy extra ultrasound working station which is really complicated and waste time)
- Unique One-key-light keyboard function for black room use;
- Display brightness adjustable
- Dual TV output: PAL/NTSC, can connect video printer when necessary
- Power supply：100-240V～ 1.2-0.6A frequency：50-60Hz
- Power supply adaptor output：DC12.8V 3.0A
Main Basic Configuration
- Main unit
- 6.5MHz linear rectal probe
- Power supply adaptor
- Li-battery: HYLB-1614 11.1V-4400mAh 48.84Wh
- Two probe sockets
- DICOM 3.0
- 4.0MHz Convex Rectal probe
- 6.5MHz Micro-Convex Probe for small animals
- 3.5MHz Linear Probe for eye muscle
- 3.5MHz Convex Probe
- 7.5MHz Linear Probe
- Battery charger
- Video printer（UP-897MD）
- Ethernet Switch
I was disappointed with the picture quality and I did call to get more information but there wasn’t any assistance 🤷♀️
Service is alright, but still waiting on a reply, however, not impressed with the machine. The machine will not stay powered unless plugged in, should work unplugged after fully charged.
