Cow, Sheep, Cat/Dog Pregnancy Test Machine Veterinary Imaging Doppler Ultrasound
KeeboVet
- Pregnancy testing
- Backfat measurement
- Large capacity battery, 300min
- Compact and Lightweight, under 1.5lbs
Technical Specification:
- Using the latest cortex-m4 embedded control system + miniaturized exclusive ultrasound technology hardware system; MSU3 has a triple function of A scan, B scan, and ear tag scan, the perfect solution to the various needs of users;
- 3.5"high-resolution color LCD, small size, lightweight and portable, suitable for outdoor use;
- Menu interface operation, Language: Chinese/English switchable;
- Gray:256
- Display mode: B, 2B, A, total 3 kinds.
- B mode and A mode gain range: 27 ~ 90dB
- Near field gain: -31 ~ 0dB;
- Far Field Gain: 0 ~ 31dB;
- Dynamic range:27~90dB
- 3 kinds of depth range, 126,163,200, the maximum display depth of 200mm;
- Compression curve adjustment: 4 kinds, from 0 to 3;
- Frequency: 2.5M, 3.5M;
- Frame correlation: 0 ~ 5,6 kinds;
- Pseudo-color function: 0 ~ 7,8 species (including black and white);
- Able to measure backfat thickness, muscle thickness, and lean percentage;
- Image Storage: image or measurement data stored in the U disk;
- Scale of the image display: 3 kinds, "0" is not displayed ruler, "1" is displayed 10mm pitch of dot scale, "2" is displayed vertical and horizontal pitch of 10mm dot scale;
- Supports 3 kinds ear tag format: EM4305, EM4100, T5557;
- Unique ear tag scanning function: ear tag scanning within a set time (10-30 seconds) to complete the ear tag scanning;
- B scan and A scan measured data can be stored in an Excel table, user-friendly data management, processing all kinds of information;
- Unique menu display settings: Menu disappears automatically at a set time, user-friendly observation image;
- Screen saver function;
- System settings probe guard time, automatically freeze, protect probe;
- Support multiple languages: Chinese, English, French, German, Spanish, Portuguese;
- Dual power supply. Power: 100-240V ~ ± 10% 1.2-0.6A Frequency: 50-60Hz ± 1Hz;
- Battery Configuration: Large capacity (2600mAh) lithium battery can support more than 300 minutes of work;
- Net Weight: 620g;
- Main unit size:90×98×25mm(length x width x height)
| Standard Configuration: | |
| 1 | Main unit: 1 pc |
| 2 | 3.5MHz mechanical sector probe: 1 pc |
| 3 | Power adapter: 1 pc |
| 4 | Internal battery : 1pc |
| 5 | Power line: 1 pc |
| 6 | Shutter release line: 1 pc |
| 7 | Straps: 1 pc |
| 8 | Instrument backpack: 1 pc |
| 9 | OTG U disk: 1 pc |
