Chison ECO2 on Sale- By Emails
Chison ECO2 - Powerful and Affordable B&W Ultrasound
ECO2 uses the latest advanced technologies such as: Compound Imaging, SRA, Multiple Beam-forming, and Tissue Harmonic Imaging. These improve the image quality, resolution, penetration and frame rate, and ECO is the only system that has all these advanced features on a black and white ultrasound.
ECO2 is lightweight at 14 pounds including battery. The AC adapter is very small and lightweight for travel, three times smaller than most other portable machines.
ECO2 has a medical grade LED screen to allow a brighter image outdoors, and is energy saving and eco-friendly compared to other models with LCD.
ECO2 feature's one key to full screen image, making the image as a 15" screen, while keeping the machine small and portable.
ERGONOMICS
- Rotatable LED(0~30°):tailer to different viewing angles
- Ultra-compact & Ultra-light
- Easy to carry
- Keyboard : For easy and quick access
- Dedicated cart TR 9000 (KM-6)
- Streamlined workflow
ECHO
Advanced technologies:- i-Image(Intelligent image optimization)
- THI (Tissue Harmonic Image)
- SRA(Speckle Reduction Algorithm)
- Compound imaging
- Full digital beam-former
- Trapezoid
- Automatic PW trace
- Chroma
- Full screen display mode
- AIO (Automatic image optimization)
ECONOMIC
- The latest platform & more advanced chip-set:brings you better image quality and features at less cost in a more compact box
- Support PC printer, reduce investment & day to day paper cost
- 8G memory card
- 320G harddisk (option)
- Vehicular Charging
ECO-FRIENDLY
- Less radiation
- Less power consumption
- Longer usage life: LED
- Longer battery standby time: >2 hours
SPECIFICATIONS
Applications |
Abdomen,OB/GYN,Vascular, Small parts(breast, testicles, thyroid),Musculoskeletal Conventional & Superficial, Pediatric, Basic Cardiac |
Imaging technologies |
i-Image, SRA, Compound, THI |
Display Modes |
B, B/B, 4B, M, B/M,PW |
Gray Scale |
256 Levels |
Scanning Depth |
240mm Max (depend on the probe types) |
Probe Frequency |
2.5 MHz - 11.0 MHz (Depend on the probe) |
Cine Loop |
256 frames |
Zoom |
4 steps |
Software Packages |
Dedicated measurement package: General ,OB/GYN, URO,Cardiac, Vascular, Small parts |
Archives Management |
Patient information management, images record, exam report |
Power Supply |
AC 100V-240V, 50Hz- 60Hz |
Standard Configuration |
2 probe connector, 3 USB ports,VGA port,Video port, LAN port, Full Screen Display Mode, i-Image,Chroma, SRA, Compound imaging,THI, 8G memory card, PW Mode, Built-in Battery, Support PC Printer, DICOM 3.0, Carrying Case (BG—100 ) |
Option |
Water-proof keyboard cover, Cart TR 9000, Video Printer, PC Printer |
