On Sale

KX5600V LED Screen DICOM

Sale price

Regular price $3,999.00
( / )

Amazing quality for low price!  DICOM included!

You can buy KX5600V only from Keebomed. Portability, good image quality and affordability in one place!


  • Light weight (10 Lbs) with battery and probe included (similar ultrasounds are about 20lbs)
  • Two probe connectors like standard
  • Sole veterinary ultrasound with DICOM as standard feature.
  • Battery included like standards 4 hours
  • LED monitor enables working outside in harsh sunlit conditions without sun shade.
  • Large image-Images are displayed full screen, which is preferable even to other larger ultrasounds with 12" screen, since they do not have full screen images.
  • Anti dust and anti splash keyboard convenient when working in dirty surroundings.
  • Price--most affordable in its class--other similar model are above $4999.
  • Rectal probe has 70mm lens and produces wide 70mm images which is important for determining large follicles.


  • 10.4’ high resolution color LED backlight display with high contrast and wide viewing angle
  • Adopt ARM7 embedded control system +FPGA signal processing system + well selected ultrasound hardware system, all make the unit more stable.
  • Menu operation system with different languages (Spanish, English, French, Russian and Portuguese)
  • Two probe sockets, auto-identify different optional probe
  • Body marks:1.General 2.Bovine 3.Canine 4.Equine 5.Feline 6.Cardio 7.Swine, total 27 kinds body marks indicating probe position
  • Display mode:B、2B、4B 、B/M、M
  • Adjustable depth: 10 grades, max depth to 236mm
  • Gain:0~127dB
  • Contrast:27~90dB
  • Gray scale:256
  • 8 steps intelligent TGC
  • 8 kinds pseudo colors
  • Image storage: 4G hard disk to permanently store about 5000 frames images;
  • Cine loop:256 frames
  • Puncture guide function with 2 correctable puncture guiding lines(adjustable angle & position)
  • the gravel software package with real-time position line measurement
  • Normal measurement: Distance, circumference, area (trochoid or ellipse), volume, etc.
  • Cardio measurement:Depth, slope, heart rate, cycle
  • OB measurement including: Cattle, dogs, horses, cats, goats, camels and sheep and pre-gestational age birth
  • Other measurement: pig’s meat factor measurement
  • OB report function
  • One-key store: concise and practical
  • One-key review:fast, practical image review function
  • One-key Print
  • One-key Transfer the current frozen image to net workstation to complete its image text report and print directly
  • Concise and practical, easy operation. The system includes network workstation to complete data & report management (You don’t need to invest more to buy extra ultrasound working station which is really complicated and waste time)
  • Unique One-key-light keyboard function for black room use;
  • Display brightness adjustable
  • Dual TV output: PAL/NTSC, can connect video printer when necessary
  • Power supply:100-240V~ 1.2-0.6A  frequency:50-60Hz
  • Power supply adaptor output:DC12.8V 3.0A

Main Basic Configuration

  • Main unit
  • 6.5MHz linear rectal probe
  • Power supply adaptor
  • Li-battery: HYLB-1614 11.1V-4400mAh 48.84Wh
  • Reticle
  • Two probe sockets
  • DICOM 3.0


  • 4.0MHz Convex Rectal probe
  • 6.5MHz Micro-Convex Probe for small animals
  • 3.5MHz Linear Probe for eye muscle
  • 3.5MHz Convex Probe
  • 7.5MHz Linear Probe
  • Battery charger
  • Trolley
  • Video printer(UP-897MD)
  • Ethernet Switch
